Jeff rinsavisce e torna a fare ampli seri abbandonando la classe D
era ora
era ora
Output Power | 300 watts @ 8 ohms / 550 watts @ 4 ohms |
Frequency Response | 5 Hz – 350 kHz |
S/N Ratio | 95 dB, ref. 1.0 watt @ 8 ohm load |
Output Noise | <55 µv, 20 Hz – 20 kHz, unweighted |
Crosstalk | >91 dB @ 1 kHz, 74 dB @ 20 kHz |
Input Impedance | 10k ohms |
THD + Noise | 0.005% @ 1 kHz, 8 ohms |
Damping Factor | >200, 20 Hz - 20 kHz |
Overall Gain / Bal. or Unbal. | 27 dB |
Common Mode Rejection Ratio | >90 dB, 20 Hz – 20 kHz |
Absolute Phase Non-inverting | Pin 2 Positive |
Inputs | 1 pair balanced (XLR) |
Outputs | 2 pair parallel binding posts per channel |
Power Consumption Idle | 100 watts |
Power Consumption Standby | 1 watt |
Amplifier Weight | 54 lbs. / 24.5 kg |
Amplifier Shipping Weight | 64 lbs. / 29 kg |
Amplifier Dimensions (h/w/d) | 5.75” x 15.5” x 16.25” / 146mm x 394 mm x 413mm |
